| System Function |
| Throughput |
Up to 120 Tests/Hour |
| Methodology |
End point, Fixed time, Kinetic |
| Minimum Reaction Volume |
150µl |
| Water Consumption |
<1.8L /Hour |
| Principle |
Colorimetry, Turbidimetry |
| Sample Mode |
Random Access, STAT Sample Priority |
| Sample Reagent Probe & Mixer |
| Sample Volume |
2–50µl, step by 0.1µl |
| Sample/Reagent Probe |
One probe for Sample and Reagent with Liquid Level Detection, Vertical Collision
Detection and Reagent Volume real time monitoring function |
| Sample Disk |
40 Sample Positions |
| Sample Tube |
Primary tubes and Sample cups |
| Reagent Volume |
R1:150–450µl, R2:10–300µl, step by 1µl |
| Reagent Disk |
40 Reagent Positions, 24 hours Onboard Cooling |
| Reagent Bottles |
R1–30ml / R2–15ml |
| Mixer |
High polished Nano material mixer |
| Reaction System |
| Reaction Cuvettes |
50 cuvettes, UV plastic cuvettes |
| Reaction Temperature |
37±0.1°C |
| Heater |
Metal thermostat for Reaction disk |
| Lamp |
Halogen Tungsten Lamp, 12V20W, water cooling system |
| Optical System |
| Filter |
FMSS (Full-Sealed Matrix Spectrometric System) |
| Wavelength |
8 wavelengths: 340,405,450,510,546,578,630,670nm |
| Linearity Range |
0–3.0Abs |
| Accuracy |
0.5A: ± <0.02Abs, 1.0A: ± <0.04Abs |
| CV |
<1.0%< /td>
|
| Cal&QC |
| Detector |
Photodiode Detector Array |
| Calibration Mode |
One point linear, Two point linear, Multi-point linear, Logit-4P, Logit-5P, Spline,
Exponential, Polynomial |
| QC Rule |
Westgard multi-rule, Cumulative sum check, Twin plot |
| Software |
| Operating System |
Windows 7/10 |
| LIS Interface |
Bi-directional LIS Interface |
| PC Interface |
LAN/RJ45 |
| Others |
| Dimension |
720(L) × 450(D) × 550(H) |
| Power Supply |
AC 100-240V, 50/60Hz ± 1 Hz, 650VA |
| Net Weight |
50Kg |
